Product Introduction Of Heavy Apron Feeder:
Apron feeding machine is used to transport various bulk or loose materials from the silo horizontally or obliquely to the crusher, conveyor or other equipment. Apron feeder mining is widely used in the raw material transportation or continuous production process of building materials, metallurgy, coal, chemical industry and other industries. Heavy apron feeder then performs production connection, flow regulation, material premixing and other tasks.
Technical Parameters Of Apron Feeder Mining:
| Model Of Apron Feeder Mining | Slot Width (Mm) Of Apron Weigh Feeder | Dip Angle(°) Of Apron Weigh Feeder | Transport Speed(M/S) Of Apron Feeder Conveyor | Material Granularity (Mm) Of Apron Feeding Machine | Delivery Capacity Of Heavy Apron Feeder (T/H) |
| WB800×M | 800 | 0-25 | 0.014-0.14 | ≤350 | 20-80 |
| WB1000×M | 1000 | 0-25 | 0.014-0.14 | ≤600 | 40-120 |
| WB1250×M | 1250 | 0-25 | 0.014-0.14 | ≤700 | 40-200 |
| WB1400×M | 1400 | 0-25 | 0.014-0.14 | ≤700 | 40-250 |
| WB1500×M | 1500 | 0-25 | 0.014-0.14 | ≤800 | 40-300 |
| WB1600×M | 1600 | 0-23 | 0.014-0.14 | ≤800 | 40-320 |
| WB1800×M | 1800 | 0-23 | 0.014-0.14 | ≤900 | 40-600 |
| WB2000×M | 2000 | 0-23 | 0.014-0.14 | ≤1000 | 40-800 |
| WB2200×M | 2200 | 0-23 | 0.014-0.14 | ≤1100 | 40-1000 |
| WB2300×M | 2300 | 0-23 | 0.014-0.14 | ≤1200 | 40-1800 |
| WB2400×M | 2400 | 0-23 | 0.014-0.14 | ≤1200 | 40-1800 |
| WB2500×M | 2500 | 0-23 | 0.014-0.14 | ≤1500 | 40-2000 |
| WB3000×M | 3000 | 0-23 | 0.014-0.14 | ≤1800 | 500-3000 |
Main Structural Components Of Apron Feeder Conveyor:
Driving device of apron feeder mining: The driving device is the power and transmission part of apron feeder mining. The motor of apron feeder mining adopts variable frequency speed regulation. By adjusting the working speed, apron feeder mining can be used in conjunction with crusher and other equipment to fully utilize the efficiency of crusher or conveyor and improve the overall production efficiency of apron feeder mining.
Tensioning device of apron feeder mining: The tensioning device of apron weigh feeder is made of alloy steel and is used to adjust the tightness of the conveyor belt of apron weigh feeder. When designing the device, the differences in different terrains and materials are fully considered, and the parameters of apron weigh feeder are set to adapt to transmission at all angles.
The frame of apron feeder conveyor: The frame of apron feeder conveyor is an integrated frame, which is welded by channel steel, double T-shaped steel and steel plate. The materials used for the frame of apron feeder conveyor (channel steel, I-shaped steel) are thicker than those commonly used in the market. The frame structure is compact, and the apron feeder conveyor occupies a small space. With decades of experience, the welded frame of apron feeder conveyor is firm and tight, and it is not easy to loosen due to long-term vibration.
Technical Parameters of apron feeder mining:
| Equipment Purchased | Applied Engineering | Equipment Purchased | Applied Engineering |
| B800×3000 | Kazakhstan | B1500×7650 | Kansai Cement Co. , Ltd, Vietnam |
| B1000×3000 | Saraburi, Thailand | B1500×9000 | Saudi Arabia SPCC |
| B1000×3000 | GEDEM | B1500×11000 | Saudi Arabia SPCC |
| B1000×3000 | Thanh Som Cement Co. , Ltd, Vietnam | B1500×18000 | Vietnam Caesar Project |
| B1000×3600 | Saudi SCC | B1600×5500 | Saraburi Project, Thailand |
| B1000×5000 | Fu sin cement Co., Ltd. , Vietnam | B1600×9000 | Dalian Jinzhou Jinshan Cement Plant |
| B1000×8320 | Kenya 55TPA | B1600×9000 | GEDEM |
| B1000×9450 | Kazakhstan | B1800×8000 | Sulaymaniya Cement Co., Ltd, Iraq |
| B1000×11970 | Kazakhstan | B1800×9018 | Thanh Som Cement Co. , Ltd, Vietnam |
| B1000×18000 | Kazakhstan | B1800×10000 | THAI PRIDE CEMENT CO. |
| B1000×18000 | Kazakhstan | B2000×3500 | Dong Banh Cement , Vietnam |
| B1200×6385 | Thanh Som Cement Co. , Ltd, Vietnam | B2000×8500 | Saudi Arabia RCP |
| B1200×5000 | Thanh Som Cement Co. , Ltd, Vietnam | B2000×10000 | Taiwan (Guigang) Cement Co., Ltd. |
| B1200×3500 | Dong Banh Cement , Vietnam | B2000×15000 | Sinoma (Handan) Construction Co., Ltd. |
| B1200×6000 | Dong Banh Cement , Vietnam | B2200×10000 | Saudi Arabia SPCC Project |
| B1250×3000 | GEDEM | B2300×7000 | Pakistan project |
| B1250×4500 | Kazakhstan project | B2300×10000 | Liyang Jinfeng Cement Co., Ltd. |
| B1250×6080 | Fu sin cement Co., Ltd. , Vietnam | B2300×10000 | Anhui Zhongguangyuan Cement Co., Ltd. |
| B1250×8000 | Lucky Cement Co. Ltd., Pakistan | B2300×10000 | Jiangsu Hantian Cement Co., Ltd. |
| B1250×12000 | CNBM Hangzhou Design & Research Institute | B2300×10000 | Hebei Yanzhao Cement Co., Ltd. |
| B1400×3500 | Sulaymaniya Cement Co., Ltd, Iraq | B2400×12000 | Taiwan (Yingde) Cement Co., Ltd. |
| B1400×3600 | Andriz Conch Cement | B2400×12000 | Taiwan (Guigang) Cement Co., Ltd. |
| B1400×3600 | Saudi Arabia SPCC | B1400×12042 | Kazakhstan project |
Features Of Apron Weigh Feeder:
Our apron feeder conveyor can make the material flow more uniform and continuous.
The heavy apron feeder provides stable material feeding for downstream equipment, thereby optimizing the efficiency of the heavy apron feeder production line.
The apron weigh feeder has a simple structure and is made of wear-resistant materials, which reduces the maintenance requirements and long-term operating costs of the heavy apron feeder.
Compared with other types of feeding equipment, our apron feeding machine can complete material transportation with higher efficiency and lower energy consumption.
About Us:
Liyang Sinoma was established in 2007 in Liyang, Jiangsu. It is an international engineering service provider integrating R&D, design, processing and manufacturing, and technical consulting services of apron feeding machine. We can provide customized product services according to customers' specific needs for apron feeding machine to meet customers' needs for apron feeding machine. At the same time, we provide stable and reliable apron feeding machine logistics services and take appropriate apron feeding machine safety measures to prevent apron feeding machine from being damaged or lost during transportation. We are a company specializing in manufacturing apron weigh feeder and other equipment. If you have any needs and questions about apron weigh feeder, please feel free to contact us.
